The Gateron Magnetic Spark Switch is next-gen keyboard tech that's about to change how you think about key switches. These magnetic Hall Effect (HE) switches ditch traditional physical contacts for magnetic sensing, which means they'll outlast regular switches by a massive margin and give you buttery-smooth linear action every single time.
With a 45gf bottom-out force and 3.2mm total travel, these switches hit that sweet spot between gaming responsiveness and typing comfort - perfect whether you're fragging noobs or cranking out work projects. The magnetic sensing tech means you can potentially adjust actuation points and create custom curves, giving you way more control than traditional mechanical switches ever could.
Built with a PC stem and upper housing plus a durable PA66 base, these switches come factory-lubed right out of the box so you get that premium feel without the modding hassle. The 2-pin design makes them compatible with most magnetic-capable PCBs, and they're designed to work great for both office productivity and intense gaming sessions. If you're building a custom board or want to experience the future of keyboard switches, the Magnetic Spark is your ticket to that next-level typing experience.
This switch embodies the perfect fusion of precise engineering and expressive aesthetics. Whether you're a competitive gamer, custom keyboard builder, or collector, this switch brings RGB brilliance and peak tactile performance to your setup.
| Kind | Magnetic / HE |
| Type | Linear |
| Profile | |
| Operation Force | |
| Bottom out Force | 45 +/- 10gf |
| Pre-Travel | |
| Total Travel | 3.2 +/- 0.1mm |
| Spring | 22mm |
| Sound Level | |
| Operation Life | |
| Suitable For | Office and Gaming |
| Finger Strike Feeling | |
Housing | |
| Stem | PC |
| Upper Housing | PC |
| Housing Base | PA66 |
| Spring Material | |
| Mounting Pins | 2 Pin |
| Lubrication | Yes, Factory |
| SMD LED Support | |
| Initial magnetic flux | 122 +/- 8GS (PCB1.2mm) |
| Bottom-out magnetic flux | 550 +/- 30GS (PCB1.2mm) |
